Features
Caregiver Control : 7″ full color touch screen panel
Warning Mode
Air Mode : 27°C – 38°C, 1° C resolution
Skin Mode : 34°C – 37°C, 5° C, 0,1° C resolution
Warming Up Time : Less than 30 minutes
Safety Alarms : Temperature out of limit, Sensor defect, Sensor detached
Additional Alarms : Apgar time 1,3,5,10 minutes
Safety (Automatic Off) :
– Air more than 40° C,
– Temperature setup
– 3° C deviation from setting
Examination Lamp : 3 watt LED
Construction Material (Frame) :
– Steel sheet and steel tubing
– Finished with powder coating
Mattress
Mattress size : 73 x 53 x 5 cm
Mattress height from ground : Approx 91 cm
Mattress slope : Adjustable manually – 15° to 15°
Rotate : Head part 180° & Mattress 360°
X-Ray Cassette Tray : YES
IV Pole : Adjustable with fixation clamp
Heater : 500 watt quartz heater
Temperature Controller : PID System
Temperature Sensor : Air Sensor & Skin Sensor
Castor
Diameter : 5″
Swivel : 360°
Brakes : Castor with stopper
Brakes type : Two castors with lock
Specification
110 (L) x 60 (W) x 190 (H) cm
Max Patient Weight : 10 kg
Electrical Power Required, VAC : 220 V, 50 Hz
